HYVD-Dehydration Screen/Fine Sand Recovery Machine

Product electronic sample: https://www.yunzhan365.com/bookcase/sbhc/



Introduction to fine sand recycling machine:

Hengyuan·China's fine sand recovery machine is a device for the development of dewatering, de-intermediation and de-sludge of slurry materials. The biggest feature of this machine is that it can solve the problem of fine sand loss in the sand making industry. Fine sand recovery machine is also called tail sand recovery machine, fine sand extraction machine, fine sand collecting machine, sediment separator, mud separator, sand water mixture treatment system and so on.



Fine sand recycling machine principle:

The pumped sand water mixture is sent to the mud-sand high-pressure separator, and the tailing sand concentrated by centrifugation is supplied to the dewatering sieve through the grit nozzle. After dewatering by the dewatering sieve, the tail sand is effectively separated from the water, and a small amount of tail sand and mud are returned to the tank. Return to the cleaning tank, when the liquid level of the cleaning tank is too high, it is discharged through the discharge port. The weight of the recovered material in the dewatering sieve is 70%-85%. Adjusting the fineness modulus can be achieved by changing the pump speed, changing the mortar concentration, adjusting the amount of overflow water, and replacing the mortar nozzle. This completes the functions of cleaning, dehydration and classification.



Fine sand recycling machine features:

1. In the traditional artificial sand wet processing process, the spiral sand washing machine used for washing mud and dewatering of artificial sand, the loss of fine sand in artificial sand can hardly be controlled. The use of Hengyuan·China fine sand recovery machine can effectively reduce the loss of fine sand, so that it can be controlled within 5%-10%, which can solve the fineness modulus of finished sand in artificial aggregate processing system. The problem of high and low stone powder content.

2. The vibrating screen adopts a polyurethane screen which has a longer life than other types of screens and does not block holes.

3. The fine particles are fully recovered, which reduces the workload of the sedimentation tank and reduces the cleaning cost of the sedimentation tank.

4. The brigade is lined with polyurethane, which improves the service life of the whole device and can smoothly complete the work of slurry concentration and liquid clarification.

5. 85% of the largest recyclable emissions of fine-grained materials, with unparalleled technical and managerial advantages of other equipment.

6, reduce the fine material stacking time, can be directly transported, supply the market.

7. Different solutions can be designed according to different requirements of users.



Fine sand recovery machine parameters:
